Introduction: Visualizing Sound Through Fire in 3D
More by the author:
About: I am a physics student at Wheaton College who likes building interesting physics demos and other stuff that I think is awesome!
After building a reuben tube I was inspired by youtube videos of "Pyroboards" and "Firetables". This was my attempt to create the same effect that I saw in the video. This attempt was only semi-successful and there were known design flaws in the whole setup. The goal when creating this was to replicate the 3D sound effect as cheaply and as quickly as possible. So rather than use a membrane to separate the speaker from the gas chamber it was just placed right inside for simplicity. However I think that when used for short periods of time this design works well and I decided to post it here so others could maybe take inspiration and modify the design. My recommendations for improving the design are listed in the last step of this instructable
Step 1: Gathering Materials
Materials:
- Matching set of cookie pans
- Silicone sealant
- 5 feet of 3/8’’ polyutherane tubing
- T-splitter (for tubing so attach it to the pans in two places and create a uniform gas flow)
- Propane tank and regulator
- Hammer & nail (to dent the top pan in preparation for drilling)
- 1/16 inch drill bit
- Circular drill bit to drill a hole for the speaker in the pan
- drill
- speaker
* Everything was purchased an home depot except for the cookie pans
- Matching set of cookie pans
- Silicone sealant
- 5 feet of 3/8’’ polyutherane tubing
- T-splitter (for tubing so attach it to the pans in two places and create a uniform gas flow)
- Propane tank and regulator
- Hammer & nail (to dent the top pan in preparation for drilling)
- 1/16 inch drill bit
- Circular drill bit to drill a hole for the speaker in the pan
- drill
- speaker
* Everything was purchased an home depot except for the cookie pans
Step 2: Drilling the Cookie Pans
The first step is to prepare the two halves of the cookie pans that will become the gas chamber. One half will have one big hole in it to house the speaker. The other half will have tons of smal holes drilled in a grid pattern for the gas to come out in cool fire patterns.
Bottom Half:
- Drill the big hole with a circular drill bit big enough to house your speaker
- Also drill two holes near the corners in the walls of the pan. These holes need to be big enough for 3/8'' tubing to fit into so the gas can be pumped into the gas chamber
Top Half: (This takes a long time...)
- Drill a grid of small holes in the top sheet. I suggest first marking the grid with a sharpie Then denting each mark with a hammer and nail and finally drilling the holes. The closes the holes the better resolution your fire visualizer will have and the cooler it will look.
Bottom Half:
- Drill the big hole with a circular drill bit big enough to house your speaker
- Also drill two holes near the corners in the walls of the pan. These holes need to be big enough for 3/8'' tubing to fit into so the gas can be pumped into the gas chamber
Top Half: (This takes a long time...)
- Drill a grid of small holes in the top sheet. I suggest first marking the grid with a sharpie Then denting each mark with a hammer and nail and finally drilling the holes. The closes the holes the better resolution your fire visualizer will have and the cooler it will look.
Step 3: Sealing the Two Halves Together
Once Both Halves are drilled you will have to seal everything together with silicone. Before the two halves are sealed together a few components need to be sealed
Bottom Half:
- Seal two sections of tubing to the gas holes in the walls of the bottom pan
- Seal the speaker in the circular opening that we made earlier
Once the bottom half is good to go then just seal the two halves together with silicone and then cover with duct tape for good measure.
Bottom Half:
- Seal two sections of tubing to the gas holes in the walls of the bottom pan
- Seal the speaker in the circular opening that we made earlier
Once the bottom half is good to go then just seal the two halves together with silicone and then cover with duct tape for good measure.
Step 4: Setting Up the Gas System
The gas system is made by modifying a normal propane torch regulator to provide more gas flow and using a t connector and tubing to connect everything together.
Modfying the regulator:
- Unscrew the piece on the end
- Drill into the tiny pinhole to widen everything out I think that i used a 1/16 inch drill bit to widen out the regulator
Setting up the T-connector:
- It takes a bit of pressure to fit everything the tubing onto the T-connector but make sure that you have an airtight seal
- Make sure that you have cut the tubing long enough that there is space for everything to move around without causing trouble
Modfying the regulator:
- Unscrew the piece on the end
- Drill into the tiny pinhole to widen everything out I think that i used a 1/16 inch drill bit to widen out the regulator
Setting up the T-connector:
- It takes a bit of pressure to fit everything the tubing onto the T-connector but make sure that you have an airtight seal
- Make sure that you have cut the tubing long enough that there is space for everything to move around without causing trouble
Step 5: Firing It Up!
Setting up the speaker:
When all of the silicone is dry then you should test out your speaker. If you don't have one you should connect your speaker to a driver (instructions for a driver can be found on instructables or you could modify the original housing that your speaker came in by just extending the wires or something).
Fire:
Once your speaker is working screw the propane tank into the regulator gently turn the knob on the propane regulator. Then use a lighter to light the gas coming out to the grid on holes like lighting a grill. Then you can play sounds through the speaker and should observe some pretty cool effects.
Recommendations for averting the same fate as the apparatus shown in the video:
* If you followed the design exactly as presented in this instructable then the temperature will eventually reach the flash point of the conducting paper that the speaker is made of and the speaker will burn and oxygen will enter the gas chamber causing problems. *
- I would recommend trying to attach a rubber membrane over the hole in the bottom plate or maybe even connect a pipe to the bottom hole and then setup a rubber membrane and a speaker like you would for a ruben tube. Anything to separate the speaker from the heat generated by the fire would be beneficial for this design. Perhaps just making the gas chamber bigger would have solved the problem. Anyway If you decide to build this be careful and have fun with your flaming sound visulizer!
